Effect. More...
#include <Abil.h>
Detailed Description
Effect.
- Remarks
- Unknown
Member Data Documentation
◆ Activity
| CStringLink CAbilEffect::Activity |
Activity.
Determines the text displayed in the unit info panel while an order for this ability is active.
◆ AINotifyEffect
| CEffectLink CAbilEffect::AINotifyEffect |
AI Notify Effect.
◆ AlertArray
| std::vector<CAlertLink> CAbilEffect::AlertArray |
Alert Array.
Links to the alerts that will play at the different stages of the ability.
- Remarks
- indexEnum: EAbilEffectStage
◆ Arc
| CFangleArc CAbilEffect::Arc |
Arc.
Controls the arc around the caster that the target of the ability must be in. Example 360 is all around, 90 is a cone in front. If the target is outside this arc when the ability is cast, the caster will turn until the target is inside the arc.
- Remarks
- minValue: 0
- maxValue: 0
◆ ArcSlop
| CFangleArc CAbilEffect::ArcSlop |
Arc Slop.
If the target is moving, how far past the initial arc are they allowed to move before casting is cancelled.
- Remarks
- minValue: 0
- maxValue: 0
◆ AutoCastAcquireLevel
| EAcquireLevel CAbilEffect::AutoCastAcquireLevel |
Auto Cast Acquire Level.
◆ AutoCastFilters
| CTargetFilters CAbilEffect::AutoCastFilters |
Auto Cast Filters.
Auto Cast Target Filters
◆ AutoCastRange
| CFixed CAbilEffect::AutoCastRange |
Auto Cast Range.
The range at which auto casting can be triggered.
- Remarks
- minValue: 0
- maxValue: 0
◆ AutoCastValidatorArray
| std::vector<CValidatorLink> CAbilEffect::AutoCastValidatorArray |
Auto Cast Validators.
The ability will only auto cast if the validators specified here all return true.
◆ CalldownEffect
| CEffectLink CAbilEffect::CalldownEffect |
Calldown Effect.
◆ CancelableArray
| CFlagArray<e_abilEffectStageCount> CAbilEffect::CancelableArray |
◆ CancelCost
| std::vector<SCost> CAbilEffect::CancelCost |
Cancel Cost.
◆ CastIntroTime
| std::vector<CGameTime> CAbilEffect::CastIntroTime |
Cast Start Time.
The duration of the Cast phase
- Remarks
- minValue: 0
◆ CastOutroTime
| std::vector<CGameTime> CAbilEffect::CastOutroTime |
Cast Finish Time.
The minimum amount of time the casting unit must be in the Channel phase
- Remarks
- minValue: 0
◆ Cost
| std::vector<SCost> CAbilEffect::Cost |
Cost.
Cost parameters for the ability
◆ CursorEffect
| std::vector<CEffectLink> CAbilEffect::CursorEffect |
Cursor Effect.
To make an Area of Effect cursor display for this ability, hook up a Search Area effect to this field, and create a Splat actor that inherits from Cursor Splat.
◆ DefaultError
| CCmdResult CAbilEffect::DefaultError |
Default Error.
◆ Effect
| std::vector<CEffectLink> CAbilEffect::Effect |
Effect.
Selects the effect that will be applied. Specifying multiple effects here will let you choose an effect per level of this ability.
◆ EffectRange
| std::vector<CfRange> CAbilEffect::EffectRange |
Effect Range.
- Remarks
- minValue: 0,0
- maxValue: 0,0
◆ ErrorAlert
| CAlertLink CAbilEffect::ErrorAlert |
Error Alert.
The Alert that will happen if the ability cannot be cast.
◆ FinishTime
| std::vector<CGameTime> CAbilEffect::FinishTime |
Finish Time.
The duration of the Finish stage, which occurs after the effect has been applied.
- Remarks
- minValue: 0
◆ Flags
| CFlags CAbilEffect::Flags |
◆ IgnoreFilters
| CTargetFilters CAbilEffect::IgnoreFilters |
Ignore Filters.
◆ InheritAttackPriorityArray
| CFlagArray<e_abilEffectStageCount> CAbilEffect::InheritAttackPriorityArray |
Inherit Attack Priorities.
- Remarks
- indexEnum: EAbilEffectStage
◆ LearnButtonImage
| std::vector<CImagePath> CAbilEffect::LearnButtonImage |
Learn Button Image.
◆ LearnButtonName
| std::vector<CStringLink> CAbilEffect::LearnButtonName |
Learn Button Name.
◆ LearnButtonTooltip
| std::vector<CStringLink> CAbilEffect::LearnButtonTooltip |
Learn Button Tooltip.
◆ LearnButtonTooltipImage
| std::vector<CImagePath> CAbilEffect::LearnButtonTooltipImage |
Learn Button Tooltip Image.
◆ LevelButtonImage
| std::vector<CImagePath> CAbilEffect::LevelButtonImage |
Level Button - Image.
◆ LevelButtonName
| std::vector<CStringLink> CAbilEffect::LevelButtonName |
Level Button - Name.
◆ LevelButtonTooltip
| std::vector<CStringLink> CAbilEffect::LevelButtonTooltip |
Level Button - Tooltip.
◆ LevelButtonTooltipImage
| std::vector<CImagePath> CAbilEffect::LevelButtonTooltipImage |
Level Button Tooltip Image.
◆ Marker
| SMarker CAbilEffect::Marker |
Marker.
◆ PauseableArray
| CFlagArray<e_abilEffectStageCount> CAbilEffect::PauseableArray |
Pauseable Stages.
- Remarks
- indexEnum: EAbilEffectStage
◆ Placeholder
| CUnitLink CAbilEffect::Placeholder |
Placeholder Unit.
Ghost placement image for the ability
◆ PreemptableArray
| CFlagArray<e_abilEffectStageCount> CAbilEffect::PreemptableArray |
Preemptable Stages.
- Remarks
- indexEnum: EAbilEffectStage
◆ PrepTime
| std::vector<CGameTime> CAbilEffect::PrepTime |
Prepare Time.
Duration of the Prepare stage, which occurs in between Approach and Cast.
- Remarks
- minValue: 0
◆ ProducedUnitArray
| std::vector<CUnitLink> CAbilEffect::ProducedUnitArray |
Produced Unit.
◆ ProgressButtonArray
| std::vector<CButtonLink> CAbilEffect::ProgressButtonArray |
Progress Buttons.
An array of buttons that display at different stages of the ability.
- Remarks
- indexEnum: EAbilEffectStage
◆ Range
| std::vector<CFixed> CAbilEffect::Range |
Range.
Casting range of the ability
- Remarks
- minValue: 0
- maxValue: 0
◆ RangeSlop
| CFixed CAbilEffect::RangeSlop |
Range Extra.
How much further a target unit may move away from the initial targeted position before casting is cancelled.
- Remarks
- minValue: 0
- maxValue: 0
◆ RefundArray
| CFlagArray<e_abilEffectStageCount> CAbilEffect::RefundArray |
Refundable Stages.
- Remarks
- indexEnum: EAbilEffectStage
◆ RefundFraction
| SCostFactor CAbilEffect::RefundFraction |
Refund Fraction.
The fraction of the costs that will be returned if the ability is cancelled.
◆ ShowProgressArray
| CFlagArray<e_abilEffectStageCount> CAbilEffect::ShowProgressArray |
Show Progress.
The stages of the ability that a progress bar should appear for the caster.
- Remarks
- indexEnum: EAbilEffectStage
◆ SmartPriority
| uint32 CAbilEffect::SmartPriority |
Smart Priority.
Determines how important this ability is versus other abilities with a smart priority when deciding which ability should handle a smart command (usually bound to right click).
◆ SmartValidatorArray
| std::vector<CValidatorLink> CAbilEffect::SmartValidatorArray |
Smart Validators.
◆ TargetFilters
| std::vector<CTargetFilters> CAbilEffect::TargetFilters |
Target Filters.
Target unit types on which the ability can be used
◆ TargetSorts
| STargetSorts CAbilEffect::TargetSorts |
Target Sorts.
Determines how the ability prioritizes potential targets.
◆ TrackingArc
| CFangleArc CAbilEffect::TrackingArc |
Tracking Arc.
- Remarks
- minValue: 0
- maxValue: 0
◆ UninterruptibleArray
| CFlagArray<e_abilEffectStageCount> CAbilEffect::UninterruptibleArray |
Uninterruptible.
The stages at which the ability is uninterruptible.
- Remarks
- indexEnum: EAbilEffectStage
◆ UseMarkerArray
| CFlagArray<e_abilEffectStageCount> CAbilEffect::UseMarkerArray |
Markers Used.
- Remarks
- indexEnum: EAbilEffectStage
◆ ValidatedArray
| CFlagArray<e_abilEffectStageCount> CAbilEffect::ValidatedArray |
Validate.
- Remarks
- indexEnum: EAbilEffectStage
The documentation for this class was generated from the following file:
